K-Dense-AI/scientific-agent-skills

1. Purpose & Core Functionality – Overview

Decision: If you need a modular framework that turns large‑language‑model (LLM) capabilities into reproducible scientific workflows, install the K‑Dense‑AI/scientific‑agent‑skills repository and use its skill‑based architecture as the basis for your agent.

The project provides a library of “skills”—self‑contained Python modules that perform a single scientific operation (e.g., unit conversion, data‑frame summarisation, statistical‑test selection). An orchestrator loads the skills at runtime, lets an LLM plan a sequence of actions, and executes the plan in a deterministic, auditable environment. In practice, the framework lets you:

• Define a catalog of domain‑specific actions (e.g., fetching spectra, fitting a regression, generating a LaTeX report).
• Allow a language model to select and chain those actions from a natural‑language request.
• Execute each action in a sandboxed Python function with explicit inputs and outputs, preserving reproducibility.

For teams already using LLMs for literature review or hypothesis generation, the repository offers a concrete way to move from suggestion to action while keeping the code base maintainable.

---

2. Repository Architecture – Modules & Organization

The repository follows a standard Python package layout. The top‑level src/ directory holds the core engine; src/skills/ contains the individual skill definitions.

Core abstraction – BaseSkill

All skills inherit from BaseSkill, which enforces a uniform interface:

class BaseSkill(ABC):
    name: str                     # Human‑readable identifier
    input_schema: dict            # JSON‑schema describing required fields
    output_schema: dict           # JSON‑schema for the result

    @abstractmethod
    def execute(self, **inputs) -> dict:
        """Run the skill and return a dictionary matching output_schema."""

Because every skill follows this contract, the orchestrator can treat them as interchangeable building blocks. The orchestrator also includes a skill registry (SkillRegistry) that discovers all subclasses automatically at import time, so new modules can be added without changing the core engine.

---

3. Getting Started – Prerequisites, Installation, & Environment Setup

3.1 System requirements

• Python 3.10 or newer – the code uses type‑hinting introduced in 3.10.
• Access to an LLM endpoint (e.g., OpenAI gpt‑4o, Anthropic Claude, or a self‑hosted model). The repository does not include a model; you must supply an API key.
• Optional: Docker 20.10+ if you prefer containerised execution.

3.2 Clone the repository

git clone https://github.com/K-Dense-AI/scientific-agent-skills.git
cd scientific-agent-skills

3.3 Choose an environment strategy

3.4 Install dependencies

The repository lists runtime requirements in requirements.txt. After activating your chosen environment, run:

pip install -r requirements.txt

Key dependencies include:

• pydantic – input validation against the JSON schemas.
• openai, anthropic, or cohere – client libraries for LLM APIs.
• numpy, pandas, scipy, matplotlib – core scientific stack.

If you use Docker, the Dockerfile already installs these packages, so a manual pip step is unnecessary.

3.5 Configure API credentials

Create a .env file in the project root (the code loads it via python‑dotenv). Example:

OPENAI_API_KEY=sk-xxxxxxxxxxxxxxxxxxxx
ANTHROPIC_API_KEY=...

Only set the variable that matches the LLM you intend to use. The orchestrator raises a clear error if the required key is missing.

3.6 Run the built‑in demo

python -m src.examples.run_demo "Analyse the CSV file data/temperature.csv for seasonal trends and produce a short report."

The command triggers the agent, which will:

1. Ask the LLM to produce a plan (e.g., load CSV → compute monthly averages → run a Fourier analysis → plot results).
2. Execute each skill in the prescribed order, passing outputs forward.
3. Return a Markdown report with embedded figures.

If the demo completes without errors, the installation is functional.

---

4. Extending the Skills – Building Custom Scientific AI Agents

4.1 Inspecting the built‑in catalogue

The orchestrator registers all BaseSkill subclasses automatically. To list available skills:

from src.agent import SkillRegistry
print(SkillRegistry.list_skills())

You can restrict the agent to a subset of skills by supplying a list of names at construction:

agent = Agent(
    llm=OpenAIClient(),
    allowed_skills=["unit_conversion", "stat_test", "plot_generator"]
)

4.2 Adding a new skill

1. Create a module in src/skills/, for example spectral_fit.py.
2. Subclass BaseSkill and define name, input_schema, output_schema, and execute.

from src.skills.base import BaseSkill
import numpy as np
from scipy.optimize import curve_fit

class SpectralFitSkill(BaseSkill):
    name = "spectral_fit"

    input_schema = {
        "type": "object",
        "properties": {
            "wavelength": {"type": "array", "items": {"type": "number"}},
            "intensity": {"type": "array", "items": {"type": "number"}},
            "model": {"type": "string", "enum": ["gaussian", "lorentzian"]},
        },
        "required": ["wavelength", "intensity", "model"]
    }

    output_schema = {
        "type": "object",
        "properties": {
            "parameters": {"type": "array", "items": {"type": "number"}},
            "fit_quality": {"type": "number"},
        },
        "required": ["parameters", "fit_quality"]
    }

    def execute(self, **inputs) -> dict:
        wl = np.array(inputs["wavelength"])
        I = np.array(inputs["intensity"])

        if inputs["model"] == "gaussian":
            def model_func(x, a, mu, sigma):
                return a * np.exp(-0.5 * ((x - mu) / sigma) ** 2)
        else:
            def model_func(x, a, mu, gamma):
                return a * gamma**2 / ((x - mu) ** 2 + gamma**2)

        popt, _ = curve_fit(model_func, wl, I)
        residual = I - model_func(wl, *popt)
        fit_quality = 1 - np.var(residual) / np.var(I)

        return {"parameters": list(popt), "fit_quality": float(fit_quality)}

3. Register the skill – no extra code is needed; the SkillRegistry discovers it on import. Ensure the module is imported early, for example by adding import src.skills.spectral_fit to src/skills/__init__.py.
4. Document the new skill – add its description and schemas to docs/skill_catalogue.rst so users can discover it.

4.3 Modifying an existing skill

If you need a different default behavior, subclass the original and override execute. Register the subclass under a new name to avoid breaking agents that rely on the original.

class UnitConversionSkillV2(UnitConversionSkill):
    name = "unit_conversion_v2"

    def execute(self, **inputs) -> dict:
        result = super().execute(**inputs)
        if inputs.get("source_unit") == "Kelvin" and inputs.get("target_unit") == "Celsius":
            result["value"] = result["value"] - 273.15
        return result

4.4 Using custom skills with the agent

Add the new name to the allowed_skills list when constructing the agent, or modify the list after creation:

agent.allowed_skills.append("spectral_fit")

The LLM can now include spectral_fit in its plan, provided the prompt supplies enough context for the model to recognise the need.

---

5. Demonstrations & Benchmarks – Example Workflows

The repository includes three Jupyter notebooks that showcase distinct scientific domains:

Each notebook records execution time for the LLM planning step and for the total workflow. Reported times vary with the chosen LLM and hardware; on a typical laptop (Intel i7, 16 GB RAM) using OpenAI’s gpt‑4o, planning takes roughly 1–2 seconds, while the full pipeline (including data loading and plotting) ranges from 5 to 12 seconds depending on dataset size.

Performance considerations

• LLM latency dominates the total runtime; faster endpoints or local models will reduce planning time
